Name: Pedestrian High Speed Gate Turnstile Pedestrian High Speed Gate Turnstile
Brand: Pedestrian High Speed Gate Turnstile Pedestrian High Speed Gate Turnstile
SKU: SEWO-B1 series
Price: 1 USD
Availability: InStock
Rating: 4.6 (116 reviews)

Caracteristicas Galería Descripción de producto Pida una cita

Caracteristicas

Especificaciones

Model Number: SEWO-B1 series

Feature: Pedestrian High Speed Gate Turnstile

Arm Length: 550mm

open speed: 0.4s

Housing Color: Dark Grey

Rail Material: aluminum alloy

MCBF: â‰¥5,000,000 times

Working Temperature: -40â„ƒ~70â„ƒ

Name: 5Million Times DC Motor Safety Swing Turnstile

Información básica

Model Number: SEWO-B1 series

Pago y Envío Términos

Packaging Details: Standard Exporting Wooden Case

Supply Ability: 500 Set/Sets per Month Pedestrian High Speed Gate Turnstile

Descripción de producto

Product Description

Pedestrian High Speed Gate Turnstile

Our this slim swing barrier turnstile can be used for both indoor and outdoor(with Shilter). They are optimized Pedestrian Access Control Solution for Subway ,Museum, Colleges, Commercial building, Library,

Features:

1. Slim Design for small space saving

2. 24 V DC brush-less motor+Encoder+Clutch brake provides a higher level safety
3. Uni-/Bi-direction passing
4. Higher speed. 0.4 second open/close speed
5. 5,000,000 cycles of MCBF.

Parameters

Model No:	Pedestrian High Speed Gate Turnstile
Demension:	1100*100X1000(mm)
Material:	SUS 304 Stainless steel (2.0mm thickness)
Protection Class	IP66
Power Supply	DC24V
Flap Control	360 degree slipping toothed cluth lock
Opening/closing	1sec
Motor	Direct current Brushless
Noise	≤50dB
Voltage	AC110V±10%/AC220V ±10%
Lifetime	More than 10,000,000 Times
Interface	TCP/RS485/RS232
Application	Residential, Office buildings, Banks, Stadiums School ,Library ,Playground etc
Working Environment	Indoor
Working Temperature	-40℃~80℃
Relative Humidity	5%-95%. No condensation

Advantage

1. Greatest Throughput -

Throughput of up to 1 pedestrian per second through Fastlane pedestrian speedgates means a greater return on investment and often means fewer speedgates are required, with less wasted time in queues leading to greater user acceptance.

2.Intelligent Security Gates -

Retracting or swinging glass barriers intelligently control traffic flow while maximising throughput. Barriers stay open while additional authorised people walk through - even if they are walking in the opposite direction.

3.Unsurpassed Accuracy -

Virtually eliminates false alarms. The intelligence of Fastlane enables the system to differentiate between body mass and small objects such as umbrellas etc. This increases user and guard acceptance, avoiding "tune-out" from excessive false alarms.

4.Easiest Installation and Ongoing Maintenance -

CAT 5 interconnections provide plug 'n' play simplicity. Industry proven technology and onboard diagnostics to ensure maximum system up-time.

5.Safety -

SEWO Speed gates feature up to 8 safety beams designed to stop the barriers from moving in the event that any of the beams are broken. The units feature a fire alarm input to allow for unimpeded emergency egress and the units can be configured to fail safe in the event of power fail.

6.Disabled Access -

SEWO Speed gates can be installed in a number of ways to allow for wheelchair access to make the installation compliant with the UK Disabilities and Discrimination Act (DDA) as well as most similar international standards. Audio and visual feedback is provided as standard.

7.More Secure -

IR detection matrix provides unsurpassed tailgate detection and deterrence; tailgaters are detected following as close as 5 mm behind authorised users.

Detailed Images

Our Company

Shenzhen Sewo Science & technology Co.,Ltd

1.OEM, ODM is available.
2.factory is in shenzhen with best production capability ,best quality control, Best Service.
3.100% QC inspection Before Shippment.
4. CE approved,competitve price,fast delivery!

5. More than 14years experience in pedetrian access control system and car parking system, warmly welcome to consult with us, we will be on your service all the time,thank you!

Different coutnries exhibition we had attended(like the above pictures), including at Germany, Mexico, Dubai, USA etc.. we get much experience in this field, if interested in them, just contact me at sewo208 at szsewo.com, or whats app:86 15814055829, thanks a lot!

Packing & Delivery

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
